GT-5X10
Low-Pro / HYDRAULIC DUMP TRAILER

GVWR: 7000lbs.

GAWR: 3500lbs.

Curb Weight: 1895lbs.

Payload: 5105lbs.

Dump Capacity:3000lbs.

Width: 5ft. / 60"

Length: 10ft. / 120"

Overall Length: 159"

Tongue: 2" X 4" Tube

Tongue Weight (est.): 280lbs.

Griffin Trailers

GRIFFIN

TRAILER™
Griffin Trailers - Bed Specifications
Width: 59.5"
Coupler Height: 18"
Length: 10ft. / 120"
SIDEWALL HEIGHT: 16"
FLOOR HEIGHT: 29"
Cross Members: 2" X 3" Tube
Ideal for a light duty tow vehicle, the GT-5X10 features a 10 foot bed length and a tandem axle to accommodate more payload than the GT-5X8. The durable design gives even the home project enthusiast a commercial quality hauler at an affordable price.

STANDARD FEATURES

• 3 Year Limited Structural / OEM Component Warranty
• 2-5/16" A-Frame Coupler
• 12v DC Hydraulic Pump - (3200 PSI Pwr Up) (1500 PSI Pwr Down)
• Black Powder Coat WHEELS
• 15" Radial TIRES
• Interstate Deep Cycle Marine Battery
• Coupler Mounted, 5000lb. Top Wind JACK
• Easy Front Access - CONTROL BOX w/ KEY LOCK
• 14ga. Formed Treadplate FENDERS
• 2"x4" Tube STAKE POCKETS
• SAFETY CHAINS - (2) S-Hook -1/4"x27" 5200lbs. Cap
• Tandem - EZ Lube w/Galvanized Components AXLE(S)
• Equalized Leaf Spring SUSPENSION
• SPARE TIRE MOUNT - Welded to Body
• LIGHTING - Amber & Red LED
• 3-Piece Plug&Play WIRING HARNESS
• Tarp Brackets
• 7 Pin Round ELECTRIC PLUG
• High Gloss Black Powder Coat PAINT FINISH
• (1) 3" x 30" hydraulic cylinders LIFT SYSTEM
• 12ga. Smooth Steel FLOOR & WALLS
• Barn Door Gate REAR GATE

Standard 18" Sidewall

Single 30" Hydraulic Cylinder Lift

(2) 5200lb. S-Hook Safety Chains

Tube 2" X 3" Crossmembers on 16" Centers

OPTIONAL UPGRADES

* some options may not be available on all models.

DLH 110v. Inline BATTERY CHARGER
SPARE TIRE: Matching Tire and Rim
TARP KIT: 5'x12'-Ratcheting Black Mesh
In-COMMAND SYSTEM: WiFi / Bluetooth Based Mobile App w/Optional Upgrades
Griffin Trailers Guarantee

Our 3 year limited structural guarantee gives you peace of mind that should anything happen to the chassis of your Griffin Trailer during the coverage time, we will stand by our policy. In addition, we pass along all our brand component factory warranties. New trailer warranty registration is required (within 10 days of original sale) for the guarantee to be activated.

COLOR UPGRADE OPTIONS

GREY

ORANGE

YELLOW

BLUE

RED

GREEN

Griffin Trailers - LED Lighting

Tandem Axle w/ Formed Billet Fenders

Griffin Trailers - Control Box with Keylock

2" X 4" Tube Steel Tongue Area

Griffin Trailers - Single Axle with Billet Fenders

Standard Barn Door Rear Gate
